Film width：500/700/980mm(Customizable)
Packaging Speed:25-40Bags/Lane/Min
Sealing Type:4 Side Seal
Warranty Period:One year
Measuring:1.Piston pump 2.Peristaltic pump3.Ceramic pump 4.Rotary pump
Suitable for the packaging of various liquid and paste products:such as shampoo,mouthwash,sauce,honey,jelly,medicine liquid,gel,and infant complementary foods,etc.
·Made of food-grade 304 stainless steel and complies with GMP production standards.
·Equipped with film offset correction system to ensure the stability of bag making. ·Servo motor pulls the film to make the bag sealing more stable and the finished bag more beautiful.
·Touch screen operation,default in both Chinese and English,language can be customized.
·Major brands electrical components,PLC control,high intelligence,fast speed,high efficiency. ·Automatic film breakage recognition system,automatic alarm and shutdown,and roll flm alignment and docking device
Packing material：BOPP/Polyethylene,Aluminium/Polyethylene,Paper/Polyethylene,Polyester/Aluminizer/Polyethylene, Nylon/CPP and so on
| Model | YZ-500Y | YZ-700Y | YZ-980Y |
| Lanes | 2-4 Lanes | 3-10 Lanes | 4-16 Lanes |
| Bag width | 50-125mm | 50-125mm | 50-125mm |
| Film width | Max:500mm | Max:700mm | Max:980mm |
| Sealing Type | 4sides sealing | ||
| Packing speed | 25-40Bags/Lane/Min | ||
| Measuring | 1.Piston pump 2.Peristaltic pump3.Ceramic pump 4.Rotary pump | ||
| Cuting Type | Straight cutting/Zig zag cutting/Continuous Cutting | ||
| Bag length | 45mm-160mm | ||
| Power Supply | 50HZ/220V/2.8kw | 50HZ/220V/4.1kw | 50HZ/220V/5.5kw |
| Dimension(mm) | 1540*1300*2270 | 1790*1445*2340 | 1940*1600*2450 |
| Weight | about 900kg | about 1000kg | about 1200kg |
