Packing speed：40-90box/min
Max width of box size：Max 190*90*40mm/Min 80*20*15mm
Requirement of carton paper quality：Gray card stock:300-350g/m3White card stock/:250-350g/m3
Warranty Period:one year
Certification:CE,ISO and etc.
Machine Description
1. Full-automatic box suction, box loading, box folding and molding packaging formcompact and reasonable structure.
2. Horizontal model, cam full mechanical linkage, chain one-way transmission.
3. Model applicable size range, can be quickly adjusted to change models.
4. Adopt servo/stepping motor, touch screen, PLC programmable control system.5. Adopting photoelectric eye automatic detection and tracking system, empty package does not suck box, maximize the saving of packaging materials.
| Packing speed | 40-90box/min |
| Max width of box size |
Max 190*90*40mm/Min 80*20*15mm |
| Requirement of carton paper quality | Gray card stock:300-350g/m3White card stock/:250-350g/m3 |
| Dimension ( L * W * H ) |
(L)3316*(W)1230(H)1884mm |
| Power | 2.075KW |
| Total Power | 380V 50HZ |
