Filling range:10-3500g
Warranty Period:One year
Certification:CE,ISO and etc.
No.of working station: Eight working station
Packing speed:20-60bags/min (depends on the product weight)
Bag type:Gusseted bag, four sides sealing bag, fin seal bag, zip-lock bag, spout pouch bag, etc
Application:Suitable for Laundry detergent, beverage, raw slurry, cosmetic liquid, sauce, pet wet food, jam, ketchup, detergent, rice wine, soy sauce, rice vinegar, juice, beverage, peanut butter, chili sauce, bean paste, various liquids, etc
Advantage:Our machine uses Panasonic, Siemens, Schneider, Omron and other core components to ensure quality and stable operation.
Laundry detergent, beverage, raw slurry, cosmetic liquid, sauce, pet wet food, jam, ketchup, detergent, rice wine, soy sauce, rice vinegar, juice, beverage, peanut butter, chili sauce, bean paste, various liquids, etc
1. Stainless steel design, 304 stainless steel or food grade plastic.
2. Fully automatic integration to complete feeding, measuring, bag feeding, coding, filling, Air fillng. (exhaust), sealing and finished product output.
3.Man-machine interface, touch screen operation is intuitive and easy.
4. Intelligent adjustment. If the opening bag fails, the subsequent stations do not feed or seal the bag, so that the bag material and raw mate rial are no wasted.
5. The bag width can be adjusted quickly by the handle, saving time and labour.
6. Suitable for more bags, stand-up pouches, jug pockets, zip bags, etc.can be equipped with electronic scales, powder metering, liquid metering, to achieve fully automatic assembly line packaging.
| Model | YZGD-200R | YZGD-300R |
| No.of working station | Eight working station | |
| Bag type | Gusseted bag ,four sides sealing bag ,fin seal bag, zip-lock bag, spout pouch bag, etc | |
| Bag size | Bag width:80~200mm Bag length：80~200mm | Bag width：80~300mm Bag length：100~400mm |
| Packing speed | 20-60 bags/min (depends on the product weight) | 20-45 bags/min (depends on the product weight) |
| Filling range | 10~2500g | 10~3500g |
| Noise dB | ≤70分贝 | |
| Sealing type | Straight+Mesh | |
| Machine weight | 1400KG | 1800KG |
| Power | 380V 3P 50/60HZ3.5KW | 380V 3P 50/60HZ 5.5KW |
| Air consume | ≥0.6m3/min(customer provide） | |
| Machine measure | (L)2170mm(W)1540mm(H)1430mm | (L)2460mm(W)1870mm(H)1460mm |
| Machine frame | Exposed. all material contact parts made of 304 stainless steel:Transmission and support frames are steel | |
